TRICOM KITS & CASES.

RUGGED. DEPENDABLE. RAPID DEPLOYMENT.


TCR-HHR-01
Handheld Radio Mobile Communications Kit

  • Fly away communications kit for use with the Harris AN/PRC‐
    152 and 152A Multi‐Band Radios.
  • Rapidly install a LOS, SATCOM, or Wideband communications link virtually anywhere to include military and commercial vehicles or “TOC in a Box” applications.
  • The compact case holds a TCR‐MBA‐50 WB Wideband/Multi‐Band RF amplifier with custom heatsink for air flow cooling, two BA‐5590 style batteries (user supplied), a DC‐DC power adapter for the radio, a radio battery charger, a temperature controlled dual fan enclosure for power amplifier cooling and an egress panel for easy access to antenna, data , PA remote and input power connections. Connections are provided for a
    SATCOM antenna, LOS antenna and wideband
    antenna.
  • Each case is shipped with one piece of a waterproof USB cable (mini-B male to A male) (Tricom P/N 77500-00450)
  • Tricom part number 11000-00748

                           Radio and batteries are NOT included


                            Radios and batteries are NOT included

TCR-HHR-02
Tactical Radio Repeater
and Communications System

  • Fly away repeater and communications kit for use with
    the Harris AN/PRC‐152A family of Multi‐Band Handheld Radios.
  • Allows an operator to rapidly set up a LOS, SATCOM, or Wideband communications link in various scenarios including military and commercial vehicles or “TOC in a Box” applications in the field or shelters.
  • The two radios can be operated independently or set up as a repeater by connecting them with a retransmission cable (user supplied).
  • In a repeater application the TX side radio is amplified by a TCR-MBA-50 WB Wideband/Multi-Band RF amplifier using a custom heat sink for forced air cooling.
  • The system consists of a TCR-MBA-50 amplifier, connections for two BB-2590 style batteries (user supplied) with integrated battery chargers, and a 115/230 VAC power supply.
  • The enclosure includes an egress panel for easy access to antenna, handset, PA remote and input power connections and forced air cooling of the amplifier and radios allows the system to be operated with the case closed for environmental protection.
  • Each kit ships with:
    • DC input power cable (Tricom P/N 1035-77200-00006)
    • AC input cable (Tricom P/N 77500-00247)
    • Waterproof USB cable (mini-B male to A male) (Tricom P/N 77500-00450)
  • Tricom part number 11000-00770 (for non-wheeled case version) -- TCR-HHR-02
  • Tricom part number 11000-00848 (for wheeled case version) -- TCR-HHR-02 B
  • Item can be modified (at factory) for use with Thales 148 radios as well (Factory must be told at time of order for this feature)

TCR-HHR-02 - KDU
Tactical Radio Repeater
and Communications System

  • Fly away repeater and communications kit for use with the Harris AN/PRC-152/152A  family of Multi-Band Handheld Radios.
  • Allows operator to rapidly set up a LOS, SATCOM, or Wideband communications link in various scenarios including military and commercial vehicles or “TOC in a Box” applications in the field or shelters.
  • The two radios can be operated independently or set up as a repeater by connecting them with a retransmission cable (user supplied).
  • In a repeater application the TX side radio is amplified by a TCR-MBA-50 WB Wideband/Multi-Band RF amplifier using a custom heat sink for forced air cooling.
  • The system consists of a TCR-MBA-50 amplifier, connections for two BB-2590 style batteries (user supplied) with integrated battery chargers, and a 115/230 VAC power supply.
  • The enclosure includes an egress panel for easy access to antenna, handset, PA remote and input power connections and forced air cooling of the amplifier and radios allows the system to be operated with the case closed for environmental protection.
  • Each kit ships with:
    • DC input power cable (Tricom P/N 77500-00593)
    • Waterproof USB cable (mini-B male to A male) (Tricom P/N 77500-00450)
  • An optional AC cable is available for purchase (Tricom P/N 77500-00247)
  • Tricom part number 11000-00822
  • Item can be modified (at factory) for use with Thales 148 radios as well (Factory must be told at time of order for this feature)

                      Radios and batteries are NOT included


TC-HHR-05
Fly Away Comms Kit

                                               Radios are NOT included

                                                Speakers are included

  • The TCR-HHR-05 is designed as a fly away communications kit for use with the Harris AN/PRC-152 or Thales AN/PRC-148 Multi-Band Radios.
  • Allows an operator to rapidly install up to four Line of Site or SATCOM communications links virtually anywhere to include military and commercial vehicles.
  • Can also be configured as a dual cross-band repeater/retransmission system.
  • The compact case holds four TCR-MBA-50-WB Multi-Band RF power amplifiers (PA), two TCR-SPK-02 Dual Net Amplified Speakers, and a dual AC-DC power adapter.
  • External connections are provided for RF Antenna, radio KDU/USB, speaker remote power/audio and two 24 VDC @ 2 Amp auxiliary power connectors.
  • Each Case ships with the following items:
    • 2 pcs Dual Net Speakers (Tricom P/N 11000-00771)
    • 1 pc AC Power Cable (Tricom P/N 77500-00614)
    • 1 pc Dual Net Speaker Audio Extension Cable (Tricom P/N 77500-00615
    • 1 pc DC Out Aux Cable (Tricom P/N 77500-00649)
    • 1 pc Waterproof USB cable (Tricom P/N 77500-00450)
    • 2 pcs Dual Net Speaker Handsets (Tricom P/N 79000-00503
  • Optional accessories available for purchase:
    • 77500-00659 - KDU/USB adapter for Thales Radios
    • 77500-00621 - Fisher KDU to 152 Radio Cable
  • Tricom part number 11000-00831

                                     Radio and batteries are NOT included

TCR-MPR-01 and TCR-MPR-01B
Mobile Communications Kit

  • The Tricom Research Mobile Communications Kit is designed as a fly away communications kit for use with the Harris AN/PRC-117G Multi-Band Radio.
  • Allows an operator to rapidly install a Line of Site or SATCOM communications link virtually anywhere to include military and commercial vehicles.
  • Holds a TRC-MBA-50 Multi-Band RF amplifier, one BA5590 battery (User supplied), an AC-DC power adapter, DC-DC power adapter, an amplified speaker, and an RF switch that allows automatic selection of the radio output port to the input of the RF power amplifier based on the mode of operation selected. Connections are provided for a SATCOM antenna, LOS antenna and wideband antenna.
  • Tricom part number 11000-00707 (non-wheeled case version)
  • Tricom part number 11000-00707B (wheeled case version)

NOT SURE WHICH TRICOM RESEARCH CASE BEST SUITS YOUR APPLICATION

CHECK OUT THE CASE MATRIX BELOW
